The video wall is capable of displaying high definition graphics and video content, making it an ideal solution for public displays, digital signage, and advertising.
The LCD Video wall can be customized to suit the specific requirements of a range of environments such as corporate lobbies, trade shows, sports arenas, shopping malls, and public places.
Utilizing technology makes the manufacturing process go smoothly and efficiently.With regard to the product advantages, the product can be widely found in the field(s) of Indoor And Outdoor Support 49inch 3.5mm Hd Advertising Video Wall Lcd 3x3 Lcd Tv Wall. We can provide you with the highest quality products within your budget. The design is the most striking aspect of KOSINTEC. Its design comes from our designers who are sensitive to fashion and are know the commercial needs of the market very well. Also, LCD video walls, digital shelf displays, digital menu boards, and high brightness digital signages made of well-selected raw materials.
| Color | Black | Panel Size | 49 inch |
| Place of Origin | Guangdong, China | Model Number | KS-LW4635 |
| Brand Name | Kosintec | Function | SDK |
| Screen Size | 49 inch | Pixel Pitch | 3.5mm, 3.5mm |
| Specification | Video Wall | Item | VIDEO wall panel |
| LOGO | OEM | Size | 49 inches |
| Panel Life | About 50000 hours | LCD Brand | LG/BOE |
| Bezel | 3.5mm | External control | RS232 |
| Feature | Video Loop/Daisy Chain | Warranty | 1 Year |
| Type | Other |
Kosintec Video Wall Features
1) Original 49inch BOE Industrial grade lcd video wall screen,16:9 a-Si TFT-LCD
2) LED backlight,500nits 450nits brightness
3) FHD physical resolution 1920*1080
4) Only 3.5mm Ultra narrow bezel.High quality,practical,good vision effect
5) Signal interface rich--RS232,HD,DVI,VGA,Y Pb Pr,AV
6) HD video wall unit--High brightness,high contrast,high gamut
| LCD Technology | a-Si TFT-LCD (100% origial new panel ) |
| Model | KS-LW4635 |
| Aspect Ratio | 16:9 |
| Response Time | ≤ 5ms |
| Standby/Max Power Consumption | <3W,≤240W |
| Power Supply | AC100-240V 50/60 HZ |
| Working Time Capacity | 7x24hours |
| Surface | Anti-glare |
| Input signal | DVI,HD,VGA,CVBS I/O,RS232,ISP IN,IP IN,CODING BUTTON(optional) |
| Output signal | RS232,CVBS |
| Control signal | RS232 LOOP,RS232 via LAN (RJ45) |
Fully customizable for 3x1, 2x2, 3x2, 2x3, 4x2, 2x4 or 1x3 Video walls!
SUPER NARROW BEZEL With a bezel-to-bezel measurement of just 4.9mm (47") and 3.5mm (55") our video walls create a stunning visual canvas that is easily installed.
Higher brightness uniformity 90% ensures high quality image delivered across displays.
WIDE VIEWING ANGLE accurately displays an image is quality and color at a 178° ultra wide viewing angle.
Premium Displays present crystal clear images in both landscape and portrait orientations without hot spots until screen surface temperature rises above 230°F.
Ultra HD resolution, panel brand: Sumsung//AU.
Provides a perfectly flat viewing surface for graphic and data video projection.
Designed for permanent mounting to the wall or in a wall opening.
Q1: Are you a factory or a trading company?
A : We are a OEM/ODM factory.
Q2: What payment methods your company accept?
A : We accept most of the payment methods, Flexible Payment term: support T/T, L/C, Westunion, Paypal.
Q3: How long is the warranty time for your products?
A:1-year warranty, lifetime maintenance.
Q4: What will you do if the product be nature damange within warranty time and how about out that time?
A : Well, we will give some quite simple questions to help us confirm the damaged part. Once it confirmed, the free replacement will be send. Also, we will just request a very low price for replacement part, if the product out of warranty time.
Q5: Can I customize the product I ordered?
A : Abusolutely yes, customizatiion offer from customers are most welcome in our company.
Q6:Can I order a sample?
A:We have a very strong quality control Samples are always available for checking quality and can be dispatched to you very quickly.
Q7:What are your advantages?
A : We have our own ERP systems : Shorten lead times at low cost with responsive production planning.
Q8:What kind of design and development capabilities do you have?
A:artwork/ Instruction manual/ product design according to customer's requirement.
Q9:What's the shipment terms and delivery time of your company?
A : Well, they depends on the quantity of your order.As you know ,we need time to manufacture the machines.but mostly ,the shipment time is 3-8 working days after delivery.For Delivery way, for Sample and Bulk order < 100KG, we will kindly suggestExpress and Air freight, when Air freight and Sea shipping for Bulk order >100KG.As for detailed cost, it depends on your final order.
